Kaedra - for modular device - 2 x 12 modules - 2 terminal blocks
13433
อัตราค่าจัดส่ง
รายละเอียดสินค้า
| Range | Mureva |
|---|---|
| Product name | Mureva Enclosure |
| Product or component type | Weatherproof enclosure |
| Enclosure type | Enclosure for modular device |
| Mounting plate description | Without mounting plate |
| Enclosure mounting | Surface |
|---|---|
| 9 mm pitches | 24 |
| Number of 18 mm modules per row | 12 |
| Total number of 18 mm modules | 24 |
| Number of horizontal rows | 2 |
| Electrical insulation class | Double insulation Class II |
| Provided equipment | 2 marking kit 2 wiring strap 1 terminal block support 2 terminal block 22 holes |
| Type of front cover | Transparent Reversible |
| [In] rated current | 63 A |
| Type of rail | DIN |
| Number of pre-cutouts PG ISO | 17 |
| Number of terminal blocks | 2 earth / neutral (screw connection) with 22 outgoers |
| Distribution block outgoers | 22 x 10 mm² 22 x 16 mm² |
| Locking options description | Optional keylock |
| Enclosure material | Self-extinguishing polymer |
| Width | 340 mm |
| Height | 460 mm |
| Depth | 160 mm |
| Internal depth | 88 mm |
| Colour | Door: transparent green Enclosure: light grey (RAL 7035) |
| Standards | EN 50262 IEC 61439-3 IEC 60695-2-1 IEC 60670 |
|---|---|
| Fire resistance | 650 °C conforming to IEC 60695-2-1 |
| IP degree of protection | IP65 conforming to IEC 60529 |
| IK degree of protection | IK09 conforming to EN 50102 |
| Environmental characteristics (UV) | UV resistant: class 3 conforming to ISO 4582:2010 Ultraviolet degradation test conforming to ISO 4892-2:2013 |
| Overvoltage category | II |
| Ambient air temperature for operation | -25…60 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 17.000 cm |
| Package 1 Width | 35.500 cm |
| Package 1 Length | 47.200 cm |
| Package 1 Weight | 3.495 kg |
| Unit Type of Package 2 | P12 |
| Number of Units in Package 2 | 28 |
| Package 2 Height | 110.000 cm |
| Package 2 Width | 80.000 cm |
| Package 2 Length | 120.000 cm |
| Package 2 Weight | 109.860 kg |
| Warranty | 18 months |
|---|
